50L Fixed Type Vacuum Emulsifier Mixer Paste Lotion Making Machine SUS Material
Dettagli:
| Luogo di origine: | La Cina |
| Marca: | LIANHE |
| Certificazione: | CE , ISO , SGS , TUV |
| Numero di modello: | LH-VME-F50 |
Termini di pagamento e spedizione:
| Quantità di ordine minimo: | 1 |
|---|---|
| Prezzo: | Negotiable |
| Imballaggi particolari: | Imballaggio della cassa del compensato/film della bolla |
| Tempi di consegna: | 30 giorni lavorativi |
| Termini di pagamento: | T/T, L/C, D/A |
| Capacità di alimentazione: | 20 insiemi al mese |
|
Informazioni dettagliate |
|||
| Capacità di progettazione: | 63L | capacità lavorativa: | 50L |
|---|---|---|---|
| Capacità disponibile: | 5L-6000L | Velocità mescolantesi: | 0-65rpm |
| Velocità dell'omogeneizzatore: | 0-3600rpm | Sistema di riscaldamento: | Riscaldamento elettrico/riscaldamento di vapore |
| Sistema di vuoto: | -0.1MPa | Materiale: | SUS316L/SUS304/SUS304 (3 strati) |
| Struttura del carro armato: | Carro armato principale + serbatoio dell'olio + del serbatoio di acqua | ||
Descrizione di prodotto
50L Fixed Type Vacuum Emulsifier Mixer Paste Lotion Making Machine
Brief Introduction:
- The vacuum emulsifiers produced by our company include many varieties. The homogenizing systems include top homogenizer, bottom homogenizer, internal and external circulating homogenizer. The mixing systems include single-way mixing, two-way mixing and helical ribbon mixing. The lifting systems include single -cylinder lifting and double-cylinder lifting. Various high quality products can be customized according to customer's requirements.
- The triple mixing adopts the imported frequency converter for speed adjusment, which can meet different technological demands.
- The homogenizing structure made through German technology adopts the improted double-end mechanical seal effect. The maximum emulsifying rotation speed can reach 4,200rpm and highest shearing fineness can reach 0.2-5μm.
- The vacuum defoaming can make the materials meet the requirement of being aseptic. The vacuum material sucking is adopted, and especially for the powder materials, vacuum sucking can avoid powder floating.
- The emulsifying pot lid can adopt lifting system, easy to clean and the cleaning effect is more abvious, the emulsifying pot can adopt tilt discharge.
- The pot body is welded by imported three-layer stainless steel plate. The tank body and pipes adopt mirror polishing, which fully meet the international standards.
- All material contact parts are made of SUS316L, which can meet the manufacturing standard of cosmetic, pharmaceutical and food industries.
Technical Parameter:
| Capacity (L) | Homogenizer | Agitator | Vacuum pump | Heating system | ||||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | power (kw) | Limit vacuum | Electric heating (kw) | Steam heating (Mpa) | |
| 5 | 0.55 | 0-3600 | 0.4 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 10 | 1.1 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 20 | 1.5 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 9 | 0.2 |
| 50 | 3 | 0-3600 | 0.75 | 0-65 | 0.75 | -0.1 | 12 | 0.2 |
| 100 | 4 | 0-3600 | 1.5 | 0-65 | 1.5 | -0.1 | 24 | 0.2 |
| 200 | 5.5 | 0-3600 | 1.5 | 0-65 | 2.2 | -0.1 | 28 | 0.2 |
| 300 | 7.5 | 0-3600 | 3 | 0-65 | 2.2 | -0.1 | 32 | 0.2 |
| 500 | 11 | 0-3600 | 4 | 0-65 | 4 | -0.1 | 50 | 0.2 |
| 1000 | 15 | 0-3600 | 5.5 | 0-65 | 4 | -0.1 | 54 | 0.2 |
| 2000 | 18.5 | 0-3600 | 7.5 | 0-65 | 5.5 | -0.1 | recommend steam heating | 0.2 |
| 5000 | 22.5 | 0-3600 | 15 | 0-65 | 7.5 | -0.1 | 0.2 | |
| The parameters are for reference only, all the machines can be customized according to your needs. |
||||||||
Application Product:
This machine is suitable for cosmetic cream, paste, mayonnaise, shampoo, syrup, etc products in cosmetic, food, beverage, chemical, daily chemical, beverage, pharmaceutical, medical, etc industries. If customers have any doubt on the machine, or if you are not sure whether this machine is suitable for your products or not, please send us inquiry and we will get back to you very soon.
Main Features:
- Complex scraping board blending oar is suitable to every kind of complicated recipe and achieve optimizing effect;
- Polytetrafluroethylene scraping board cater to body of blending groove and scrape out viscosity material on boiler wall;
- Homogenizer is installed on boiler bottom to increase motor power more thoroughly and strongly. During few production, it can exert homogenizing effect fully;
- Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high -capability cut,rubbing,centrifugal to make sure exquisite and slick cream; boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation.
- Homogenizing vacuum emulsifier mixer can choose frequency conversion timing homogenizer and highest rotate speed is 3600 r/min.
Machine Details:
